Cathode material

LiFePO4

Rated voltage/V

51.2

Rated capacity/Ah

102

204

306

408

Rated energy/kWh

5.22

10.44

15.67

20.89

Standard parallel unit/P

1

2

3

4

Output power/kW

5

5

10

5

10

5

10

Charge voltage/V

58.4

Operating voltage range/V

41.6-58.4

Max. charge current /A

50

100

120

150

120

200

Max. discharge current /A

100

120

200

120

200

120

200

Operating temperature/℃

Charge temperature/℃

0~55

Discharge temperature/℃

-20~55

Weight/kg

11+50*1

11+50*2

11+50*3

11+50*4

Dimension(W×D×H)(mm)

580×390×380

580×390×560

580×390×740

580×390×920

IP rating

IP54

Certification

UN38.3, CE-EMC

Cooling method

Natural cooling

Communication

CAN/RS485

Cycle life

≥6000 Cycles@0.5C/90%DOD@70%EOL, 25±2℃

Display configuration

Quick-connect terminal, ON/OFF button, SOC indicator light
