Capacity

1000 VA / 800 W

1500 VA / 1200 W

2000 VA / 1600 W

DC INPUT

Rated voltage

24 V

36 V (S)

48 V (H)

DC input range (default)

20 ~ 30 V

30 ~ 45 V (S)

40 ~ 60 V (H)

AC INPUT

AC input range (bypass mode)

0 ~ 121 / 132 / 138 / 144 Vac for 100 / 110 / 115 / 120 Vac ± 10 Vac

0 ~ 242 / 264 / 276 / 288 Vac for 200 / 220 / 230 / 240 Vac ± 10 Vac

AC input range (mains mode)

100 V: 70 ~ 130 Vac    110 V: 80 ~ 140 Vac     115 V: 85 ~ 145 Vac

120 V: 90 ~ 150 Vac    200 V: 145 ~ 260 Vac    220 V: 165 ~ 280 Vac

230 V: 175 ~ 290 Vac   240 V: 185 ~ 300 Vac

Frequency input range

50 / 60 Hz (auto-sensing), 50 / 60 Hz ± 5% ~ 15%

Generator connection

Available (generator input power is settable)

OUTPUT

Inverter output range

100 / 110 / 115 / 120 / 200 / 220 / 230 / 240 Vac ± 5% (settable)

AC output range (bypass mode)

0 ~ 121 / 132 / 138 / 144 Vac for 100 / 110 / 115 / 120 Vac ± 10 Vac

0 ~ 242 / 264 / 276 / 288 Vac for 200 / 220 / 230 V / 240 Vac ± 10 Vac

AC output range (mains mode)

100 V: 90 ~ 110 Vac     110 V: 99 ~ 121 Vac     115 V: 103 ~ 126 Vac

120 V: 108 ~ 132 Vac    200 V: 166 ~ 226 Vac    220 V: 188 ~ 245 Vac,

230 V: 199 ~ 254 Vac    240 V: 210 ~ 264 Vac

Output frequency

50 / 60 Hz ± 0.3 Hz (settable)

Waveform

Pure sine wave

Inverter efficiency

Max. 80%

Max. 85%

Energy saving mode

Settable (< 3% load) , enter in 80 s

No-load shutdown

Settable (< 3% load), shut down in 80 s

Transfer time

≤ 10 ms

THDV (resistive load)

≤ 5%

Protections

Overload, short circuit (inverter), battery low voltage, battery overcharge, overtemperature

Overload (mains mode)

110% for 120 s, 125% for 60 s, 150% for 10 s (transfer to bypass mode)

Overload (inverter mode)

110% for 60 s, 125% for 10 s, 150% for 5 s (shut down directly)

Mute

Automatic mute in 60 s or by manual

BATTERIES

Inbuilt battery (standard model)

12 V / 7 Ah x 2

12 V / 9 Ah x 2

12 V / 9 Ah x 3

Charging current

Standard model (S): 1 A (default)

Equalizing

charge voltage

Single battery 14.1 Vdc (default), 13.6 ~ 15 Vdc adjustable

Floating charge voltage

Single battery 13.5 Vdc (default), 13.2 ~ 14.6 Vdc adjustable

Low voltage alarm point

Single battery 10.8 Vdc (default), 9.6 ~ 13 Vdc adjustable

Low voltage shutdown point

Single battery 10.2 Vdc (default), 9.6 ~ 11.5 Vdc adjustable

OTHERS

Communications

USB & RJ45 (standard), dry contacts / SNMP (optional)

Operating temperature

5℃ ~ 40℃

Operating humidity

Relative humidity ≤ 93%

Noise level

≤ 50 dB (1 m)

Tower

Dimensions (W×D×H) (mm)

144x375x215

144x440x215

Packaged dimensions (W×D×H) (mm)

230x480x320

230x545x320

Net weight (kg)

12.5

14.5

18.8

Gross weight (kg)

13.8

15.8

20.2
