Cathode material

LiFePO4

Rated voltage/V

25.6

51.2

51.2

51.2

Rated capacity/Ah

204

102

204

314

Rated energy/kWh

5.22

5.22

10.44

16.07

Standard parallel unit/P

1

1

1

1

Output power/kW

3

5

5

10

5

8

Charge voltage/V

29.2

58.4

58.4

58.4

Operating voltage range/V

20.8-29.2

41.6-58.4

41.6-58.4

41.6-58.4

Max. charge current /A

100

100

100

100

160

Max. discharge current /A

100

100

100

200

100

200

Operating temperature/℃

Charge temperature/℃

0~55

Discharge temperature/℃

-20~55

Weight/kg

53

53

90

122

Dimension(W×D×H)(mm)

440×170×690(750 with wheels)

820×170×660(710 with wheels)

460×230×850(900 with wheels)

IP rating

IP21

Certification

UN38.3, CE-EMC

Cooling method

Natural cooling

Communication

CAN/RS485

Cycle life

≥6000 Cycles@0.5C/90%DOD@80%EOL, 25±2℃

≥8000 Cycles@0.5C/90%DOD@80%EOL, 25±2℃

Display configuration

ON/OFF button, LCD touchscreen
