Cathode material

LiFePO4

Rated voltage/V

750

Rated capacity/Ah

314

628

942

1256

Rated energy/kWh

10.04

20.09

30.14

40.19

Standard parallel unit/P

1

2

3

4

Output power/kW

5

10

15

20

Charge voltage/V

1000

Operating voltage range/V

600-1000

Max. charge current /A

8.3

16.6

24.9

33.2

Max. discharge current /A

8.3

16.6

24.9

33.2

Operating temperature/℃

Charge temperature/℃

0~55

Discharge temperature/℃

-20~55

Weight/kg

15+83×1

15+83×2

15+83×3

15+83×4

Dimension(W×D×H)(mm)

700×405×520

700×405×750

700×405×980

700×405×1210

IP rating

IP65

Certification

UN38.3, CE-EMC

Cooling method

Fan cooling

Communication

CAN/RS485

Cycle life

≥8000 Cycles@0.5C/90%DOD@80%EOL, 25±2℃

Display configuration

Quick-connect terminal, ON/OFF button, SOC indicator light
