Output

AC output

Pure Sine Wave

500W

1000W

230Vac(50/60Hz)

UPS transfer time

≤20ms

USB-A (×2 output)

5V 3A(constant voltage), Max. 15W/each

USB-C (×1 output)

20W

DC5521 (×4 output)

12V±3% Max. 4A

Parallel

Na

Others

Display

LED

Material

Metal

Cooling mode

Air cooling

Switch

Button

IP rating

IP20

Dimension

(L×W×H)(mm)

320×135×245

315×210×295

Net weight (kg)

≈10.5

≈18.5

Battery

Rated power

1004.8Wh

2009.6Wh

Cell material

LFP

Cycle life

After 8000 cycles, remaining capacity ≥70%

Protections

High temperature, low temperature, overdischarge, overcharge, overload, short circuit, overcurrent protection

Input

PV voltage range

11-55V

PV current

Max. 10A

Max. 15A

AC input power

500W

1000W

AC input voltage

220-240Vac; 50/60HZ

Optimal ambient temperature

20~30℃

Discharge ambient temperature

-10~60℃

Charging ambient temperature

0~50℃

Storage ambient temperature

-20~45℃(20~30℃ suitable)

Certification

UN38.3
