PV input

Max. input power

13200W

Max.input voltage

500Vdc

Start-up voltage

80Vdc

Min.operating voltage

100V

MPPT operation range voltage

100-450Vdc

Max. input current per MPPT

20A

Max. short-circuit current per MPPT

27A

Number of MPPT

2

Battery input

Battery type

Li-ion, Lead-acid battery

Battery voltage range

40-60V

Max. charging current

135A

Max. discharging current

135A

Charging curve

3 Stages/Equalization

AC input (Grid)

Grid type

Single phase(L/N/PE)

Input voltage range

170~280Vac

Input frequency range

42Hz ~ 65 Hz

Max. input current

50A

Smart

Max. input/output power

6600W¹⁾

Max. input/output current

30A

AC output (Grid)

Rated output power

6600W¹⁾

Max. apparent output power

6600VA

Grid system mode

Single phase(L/N/PE)

Rated output voltage

230Vac(220Vac/240Vac settable)

Rated output frequency

50Hz/60Hz

Rated output current

28.7A

Max. output current

30.0A

AC output (Back-up)

Rated output power

6600W¹⁾

Max. apparent power

6600VA

Output system mode

Single phase(L/N/PE)

Rated output voltage

230Vac(220Vac/240Vac settable)

Rated output frequency

50Hz/60Hz

Rated output current

28.7A

Max. output current

50A

Transfer time

0ms

Others

Protections

Input over/under voltage protection, input over/under frequency protection, output overload, output short-circuit, radiator over temperature protection, fan fault detection etc. Arc-fault circuit-interrupter(optional)

Communications

USB/RS232/RS485, dry contact, WiFi

Dimensions(W×H×D)(mm)

370×445×174

Net weight(kg)

18

IP rating

IP65

Operating environment

-25ºC~+60ºC(>45ºC derating)

Cooling mode

Smart cooling

Altitude

3000m

Noise level at 1m

≤55dB

Installation method

Wall-mounted

Safety regulation

IEC/EN 62109-1/-2

EMC

EN 61000-6-1/-2/-3/-4
