System

Rated energy capacity

100kWh

120kWh

Rated system power

30kW

On-grid and off-grid switching time

<20ms

Max. conversion efficiency

98%

European/MPPT efficiency

97% / 99.9%

IP rating

Battery cabinet(IP54), Inverter(IP66)

Operating temperature

-25℃~+60℃(>45℃ linear derating to 60%)

Relative humidity

<95%(non-condensing)

Altitude

<4000m

Cooling method

Air cooling

Noise

<65dB

Fire protection system

Cabinet level gas fire-fighting (perfluorohexanone)/aerosol+water fire-fighting

Wired/wireless communication

RS485/WiFi/Bluetooth/LAN/CAN/DRM/Meter

Human-computer interaction

LED+APP

Standards

UL 1741-2021(UL1741SB), CSA C22.2 No 107.1-16, IEEE Std C37.90.2-2004, IEEE C62.45-2002, IEEE Std C62.41.2-2002, IEEE Std C37.90.1-2024, UL 1741-2021(UL1741SA), CSA C22.2 No 107.1-16, IEEE 1547-2018 & 1547a-2020 & 1547.1-2020(SRD V2.0), UL 1741 CRD-PCS, UL1699B, CEC, SGIP, CSIP

Dimensions(WxHxD)(mm)

800x2100x1200

Weight(kg)

≤1300

Battery

Cell

314Ah

Configuration

1P100S

1P120S

Rated energy

100kWh

120kWh

Rated voltage

320Vdc

384Vdc

Voltage range

280~365Vdc

336~438Vdc

Inverter

Inverter model

ESH30K3PHVG1-LA

PV parameters

Max. input power

60kW

Max. input voltage

1000Vdc

Input voltage range

150~950Vdc

Starting voltage

200Vdc

Max. input current per string

8×20A

Max. short-circuit current per string

8×30A

MPPT voltage range

150~850Vdc

MPPT quantity/strings per MPPT

4/2+2+2+2

Grid parameters

Rated input/output power

30kW

Voltage range

120V/208V, 3L+N+PE

Rated input current

83.3A

Rated output current

83.3A

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

Diesel engine parameters

Rated power

30kW

Voltage range

104V~127V(L-N)/208~254V(L-L)

Rated current

83.3A

Backup parameters

Rated power

30kW

Rated voltage

120V/208V, 3L+N+PE

Rated frequency

50/60Hz

Rated current

83.3A
