PV input

Max. input power

20000W

30000W

40000W

48000W

Max. input voltage

1000V

Start-up voltage

180V

MPPT voltage range

150V~850V

Max. input current

20A

Max. short circuit current

30A

Number of MPPT/max. number of PV strings

2/2+2

Battery input/output

Battery voltage range

40V~60V

Max. charge/discharge current

220A

315A

390A

415A

Max. charge/discharge power

10000W

15000W

20000W

24000W

Battery BMS communication

RS485/CAN

AC output (Backup & Smart)

Rated output power

10000W

15000W

20000W

24000W

Max. apparent output power

10000VA

15000VA

20000VA

24000VA

Rated output current

15A

22A

29A

35A

Rated output voltage/frequency

3L+N+PE, 380V/400V, 50Hz/60Hz

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

EPS switching time

<20ms

Starting surge

10s@2×rated power/60s@1.5×rated power/3min@1.2×rated power/6min@1.1×rated power

THDu

<3%(linear load)

AC input (Grid & Gen)

Max. AC charging power(grid to battery)

10000W

15000W

20000W

24000W

Max. grid input current

29A

43A

58A

60A

Max. diesel generator input current

16.8A

25.3A

33.7A

40.4A

Rated input voltage/frequency

3L+N+PE, 380V/400V, 50Hz/60Hz

Efficiency

Max. efficiency

97.5%

98.0%

European efficiency

97.00%

97.20%

MPPT efficiency

99.90%

General parameters

Display

LCD+APP

Communications

RS485/WiFi/CAN/DRM (Optional: Bluetooth/LAN/Meter)

IP rating

lP66

Operating temperature

-25℃~+60℃(linearly derating to 60% when exceed +45℃~+60℃)

Humidity

0~95%(non-condensing)

Cooling mode

Intelligent air cooling

Noise level

<65dB

Dimensions (W×H×D)(mm)

448×660×265

Net weight (kg)

45
