PV input

Max. input power

100kW

Max. input voltage

1000Vdc

Start-up voltage

200Vdc

MPPT voltage range

150~850V

Max. input current

8×20A

Max. short circuit current

8×30A

Number of MPPT/max. number of PV strings

4/2+2+2+2

Battery input/output

Battery voltage range

150~850V

Max. charge/discharge current

100A/100A

Max. charge/discharge power

60kW/60kW

Battery BMS communication

RS485/CAN

AC output (EPS & Smart)

Rated output power

60kW

Max. apparent output power

60kVA

Rated output current

72.2A

Rated output voltage/frequency

277V/480V, 3L+N+PE, 50Hz/60Hz

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

EPS switching time

<20ms

Starting surge

30s@1.1×rated power/10s@1.2×rated power/0.2s@1.5×rated power

THDu

<3%(linear load)

AC input (Grid & Smart)

Max. AC charging power(grid to battery)

120kW

Max. grid input current

144.4A

Max. diesel generator input current

92.6A

Rated input voltage/frequency

277V/480V, 3L+N+PE, 50Hz/60Hz

Efficiency

Max. efficiency

98.0%

European efficiency

97.00%

MPPT efficiency

99.90%

General parameters

Display

LED+APP

Communications

RS485/WiFi/Bluetooth/LAN/CAN/DRM/Meter

IP rating

lP66

Operating temperature

-25~+60℃(>45℃ linear derating to 60%)

Humidity

0~100%(non-condensing)

Cooling mode

Intelligent air cooling

Noise level

<65dB

Dimensions (W×H×D)(mm)

544×880×278

Net weight (kg)

88
