PV input

Max. input power

21000W

22500W

Max. input voltage

550V

Start-up voltage

120V

MPPT voltage range

120V~520V

Max. input current

26A

Max. short circuit current

39A

Number of MPPT/max. number of PV strings

3/2+2+2

Battery input/output

Battery voltage range

40V~60V

Max. charge/discharge current

275A/275A

Max. charge/discharge power

14000W

16000W

Battery BMS communication

RS485/CAN

AC output (Backup & Smart)

Rated output power

14000W

16000W

Max. apparent output power

14000W

16000W

Rated output current

60.9A

69.6A

Rated output voltage/frequency

L+N+PE, 220V/230V/240V, 50Hz/60Hz

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

EPS switching time

<10ms

Starting surge

10s@2×rated power/1 min@1.5×rated power

THDu

<3%(linear load)

AC input (Grid & Gen)

Max. AC charging power(grid to battery)

14000W

16000W

Max. grid input current

60.9A

69.6A

Max. diesel generator input current

28000A

32000A

Rated input voltage/frequency

L+N+PE, 220V/230V/240V, 50Hz/60Hz

Input voltage range

184~276Vac(L-N)

Efficiency

Max. efficiency

97.5%

European efficiency

97.00%

MPPT efficiency

99.90%

General parameters

Display

LCD+APP

Communications

RS485/WiFi/CAN/DRM(Optional: Bluetooth/LAN/Meter)

IP rating

lP66

Operating temperature

-25℃~+60℃(Linearly derating to 60% when exceed +45℃~+60℃)

Humidity

0%~95%(Non-condensing)

Cooling mode

Intelligent air cooling

Noise level

<65dB

Dimensions (W×H×D)(mm)

448×660×265

Net weight (kg)

45
