Battery pack

Model

EFP64-314

Standard parallel unit

1P20S

Cathode material

LiFePO4

Rated energy

20.1kWh

Rated voltage

64V

Voltage range

50~73V

Max. charge/discharge current

157A

Dimensions(H×W×D)(mm)

554×994×365

Weight(kg)

145

Control module

Model

EBPU1500-200

Operation voltage range

250~1000V

Rated charge/discharge current

200A

Max. charge/discharge current

250A

Operation temperature

-25℃~+55℃

AC input voltage range

85~264V

DC input voltage range

250~1000V

Dimensions (W×D×H)(mm)

554×1004×365

Packaged dimensions (W×D×H)(mm)

670×1090×525

Weight(kg)

45

Battery system

MODEL

EEB-R60-01

EEB-R120-01

EEB-R160-01

EEB-R261-01

Battery system configuration

3

6

8

13

Battery system energy

60.2kWh

120.5kWh

160.7kWh

261.2kWh

Usable energy

57kWh

114kWh

152kWh

248kWh

Operation voltage

150~219V

300~438V

400~584V

650~949V

Nominal voltage

192V

384V

512V

832V

Max. charge/discharge power

30kW

60kW

80kW

130kW

Dimensions (W×D×H)(mm)

554×1051×1527

1208×1051×1527

1862×1051×1197

2516×1051×1527

Weight(kg)

500

960

1280

2025

Rated charge/discharge current

157A

Operation temperature

-10~60℃

Storage temperature

0~35℃

DOD

95%

System efficiency

>90%

Operation humidity

5%~90%

Installation

Indoor stacking

Altitude

≤2000m

Cooling method

Cooling fan

IP rating

IP21

Communication

CAN/485

Cycle life

≥8000 cycles

Certification

UN38.3/EMC EN61000-2 EN61000-4
