PV input

Max. input power

9000W

12000W

15000W

Max. input voltage

600V

Start-up voltage

90V

MPPT voltage range

70V~540V

Max. input current

30A/22A

30A/22A/22A

Max. short circuit current

40A/30A

40A/30A/30A

Number of MPPT/Max. number of PV strings

2/2

3/2

Battery input/output

Battery voltage range

40V~60V

Max. charge/discharge current

210A/130A

210A/180A

210A/180A

210A/210A

Max. charge/discharge power

10000W/6000W

10000W/7500W

10000W/8000W

10000W/10000W

Battery BMS communication

RS485/CAN

AC output (Backup & Smart)

Rated output power

6000W

7500W

8000W

12000W

Max. apparent output power

6600VA

7500VA

8800VA

12000VA

Rated output current

25A@240V/50A@120V

31.25A@240V/62.5A@120V

33.3A@240V/66.6A@120V

50A@240V/100A@120V

Rated output voltage/frequency

L1/L2/N/PE, 120V/240V, 50Hz/60Hz

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

EPS switching time

<10ms

Starting surge

5min@1.2×rated power/1min@1.4×rated power

THDu

<3%(linear load)

AC input (Grid & Gen)

Max. AC charging power(grid to battery)

10000W

Max. grid input current

40A

52.5A

62.5A

Max. generator input power

11000W

Rated input voltage/frequency

L1/L2/N/PE, 120V/240V, 50Hz/60Hz

Efficiency

Max. efficiency

94.5%

CEC. efficiency

96.50%

MPPT efficiency

99%

General parameters

Display

LED+LCD

Communications

CAN(for BMS), RS485(for meter), RS485, CAN(for parallel), optional: WiFi/LAN

Max. operation altitude

4000m(>2000m derating)

IP rating

lP65

Operating temperature

-25℃~60℃(>45℃ derating)

Humidity

0~100%

Cooling mode

Smart cooling

Noise level

<45dB

Dimensions (W×H×D)(mm)

420×790×255

Net weight (kg)

44
