PV input

Max. input power

12000W

16000W

24000W

Max. input voltage

500V

Start-up voltage

90V

MPPT voltage range

70V~450V

Max. input current

20A

40A

40A

Max. short-circuit current

25A

50A

50A

Number of MPPT/Max. number of PV strings

2/1

2/2

3/2

Battery input/output

Battery voltage range

40V~60V

Max. charge/discharge current

140A/140A

190A/190A

250A/250A

Max. charge/discharge power

6600W/6600W

8000W/8000W

12000W/12000W

Battery BMS communication

RS485/CAN

AC output (Backup & Smart)

Rated output power

6000W

8000W

12000W

Max. Apparent output power

6600VA

8800VA

13200VA

Rated output current

30A

40A

60A

Rated output voltage/frequency

L+N+PE, 220V/230V/240V, 50Hz/60Hz

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

EPS switching time

<10ms

Starting surge

10s@2×rated power

THDu

<3%(linear load)

AC input (Grid & Gen)

Max. AC charging power(grid to battery)

6600W

8000W

12000W

Max. grid input current

41A

68.2A

Max. generator input power

6600W

12000W

Rated input voltage/frequency

L+N+PE, 220V/230V/240V, 50Hz/60Hz

Efficiency

Max. efficiency

97.3%

97.6%

European efficiency

96.5%

97%

MPPT efficiency

99%

General parameters

Display

LED+LCD

Communications

RS485/CAN(for BMS), RS485, CAN(for parallel), 1 DO, 1 DI, Wi-Fi, LAN (optional)

Max. operation altitude

4000m(>2000m derating)

IP rating

lP66

Operating temperature

-25°C~60°C

Humidity

0%~100%

Cooling method

Smart cooling

Noise level

<40dB

Dimensions (W×H×D)(mm)

367×421×215

443×679×209

Net weight (kg)

11.5

31.1
