PV input

Max. input power

7800W

Max. input voltage

500V

Start-up voltage

90V

MPPT voltage range

70V~480V

Max. input current

18A

Max. short-circuit current

25A

Number of MPPT/Max. number of PV strings

2/1

Battery input/output

Battery voltage range

40V~60V

Max. charge/discharge current

75A/75A

Max. charge/discharge power

3600W

Battery BMS communication

RS485/CAN

AC output (EPS & Smart)

Rated output power

3157W@110V, 3444W@120V, 3645W@127V

Max. apparent output power

3472.7VA@110V, 3788.4VA@120V, 4009.5VA@127V

Rated output current

28.7A

Rated output voltage/frequency

110V/120V/127V, 50Hz/60Hz, L+N+PE

Power factor

>0.99(0.8 leading~0.8 lagging)

THDi

<3%@rated power

EPS switching time

<10ms

Starting surge

10s@2×rated power

THDu

<3%(linear load)

AC input (Grid & Smart)

Max. AC charging power(grid to battery)

3600W

Max. grid input current

41A

Max. diesel generator input current

41A

Rated input voltage/frequency

110V/120V/127V, 50Hz/60Hz, L+N+PE

Efficiency

Max. efficiency

97.3%

European efficiency

96.5%

MPPT efficiency

99%

General parameters

Display

LED+LCD

Communications

CAN(for BMS), RS485, CAN(for parallel), 1×DO, 1×DI, Wi-Fi

IP rating

lP65

Operating temperature

-25°C~60°C(>45°C derating)

Humidity

0%~100%

Cooling method

Natural cooling

Noise level

<45dB

Dimensions (W×H×D)(mm)

367×421×215

Net weight (kg)

15
